Section 3 Ice Machine Operation
Part Number 000001759 3-1
Section 3
Ice Machine Operation
Component Identification
Figure 3-1. Component Identification (Typical Q460 Shown)
ICE THICKNESS
PROBE
EVAPORATOR
WATER
CURTAIN
WATER
TROUGH
ICE/OFF/CLEAN
SWITCH
WATER
PUMP
BIN SWITCH
DISTRIBUTION
TUBE
SV1604G
SV1605
HARVEST VALVE
AIR CONDENSER
REMOTE COUPLINGS
COMPRESSOR
DRAIN HOSE
WATER DUMP VALVE
WATER INLET VALVE
