282 Part Number 80-1505-3 6/11
CVD675/CVD685/CVD885/CVD1075/CVD1085/
CVD1185/CVD1285/CVD1485/CVD1486/CVD1885/
CVD2075/CVD2085/CVD3085 - 3 PHASE
L1
Ground
See Serial Plate for Voltage
Contactor
Coil
L2
(95)
(97)
(94)
(96)
(74)
(85)
Low Pressure
Switch
Contactor
Fan Cycle Control
Fan Motor
Run Capacitor
Fan Motor
Run Capacitor
T2
T1
Compressor
High Pressure
Cutout
*Condensing Unit with
Two Fans Only
L3
Fan Cycle Control
T3
L1 L2
L3
