Manitowoc SD0852A User Manual

254 Part Number 80-1479-3 7/10
S1600W
All Self-Contained Water-cooled
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.8-10.8 10.9-12.0 12.4-13.6
1 - 2.5
80/27 10.1-11.1 11.0-12.1 12.7-13.9
90/32 10.2-11.2 11.1-12.2 12.8-14.0
100/38 10.4-11.5 11.4-12.5 13.0-14.3
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 13 - 14.125 lb.
50/10 70/21 90/32
70/21 1660 1510 1350
80/27 1610 1500 1320
90/32 1600 1480 1310
100/38 1570 1450 1290
Air Temp. Around Ice
Machine 90°F/32°C
Gal/100 lbs. of Ice
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
100 150 550
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10.0 235-245 46-27 160-175 70-90
70/21.1 235-275 50-27 160-180 70-95
80/26.7 240-280 52-28 160-190 70-100
90/32.2 240-285 52-28 160-190 75-100
100/37.8 250-290 52-29 165-195 75-100
110/43.3 255-295 52-30 170-200 80-100
