Manitowoc SY0305W User Manual

Part Number 80-1479-3 7/10 245
S1400 Self-contained Water-cooled
All Self-Contained Water-cooled with a Manufacture Date
Before 0711 (November 2007)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.9-10.0 9.8-10.9 11.2-12.5
1 - 2.5
80/27 8.9-10.0 9.8-10.9 11.4-12.6
90/32 8.9-10.0 9.6-10.7 11.6-12.9
100/38 9.0-10.1 10.0-11.2 11.7-13.0
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 10 - 11 lb.
50/10 70/21 90/32
70/21 1380 1280 1130
80/27 1380 1280 1120
90/32 1380 1300 1100
100/38 1370 1250 1090
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/100 lbs. of Ice 90 145 590
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 235-245 40-28 160-175 70-90
70/21 235-245 42-29 160-175 75-100
80/27 235-260 42-30 170-195 80-105
90/32 240-270 42-30 180-200 85-110
100/38 250-280 43-30 185-200 90-110
110/43 250-285 44-31 190-205 90-115
