1. TECHNICAL SPECIFICATIONS
1
FM TUNER SECTION
Frequency Range ......................................................................................................................................
87.5 - 108.0 MHz (K, /L, /N, /U)
76.0 - 90.0 MHz (F)
Usable Sensitivity ..................................................................................................................................... IHF 1.8 V/16.4 dBf
Signal to Noise Ratio ........................................................................................................................... Mono/Stereo 70/65 dB
Distortion ............................................................................................................................................. Mono/Stereo 0.2/0.3 %
Stereo Separation ................................................................................................................................................ 1 kHz 45 dB
Alternate Channel Selectivity ........................................................................................................................ 300 kHz 60 dB
Image Rejection ........................................................................................................................................... 82 MHz 70 dB (F)
98 MHz 70 dB (K, /L, /N, /U)
Tuner Output Level..................................................................................................................... 1 kHz, 40 kHz Dev 600 mV
AM TUNER SECTION
Frequency Range .............................................................................................................................
520 - 1710 kHz (U)
531 - 1602 kHz (F, /K, /L)
LW: 152 - 282 kHz, MW: 531 - 1602 kHz kHz (N)
Signal to Noise Ratio ....................................................................................................................................................... 50 dB
Usable Sensitivity ............................................................................................................................................. Loop 400 V/m
Distortion ......................................................................................................................................... 400 Hz, 30 % Mod. 0.5 %
Selectivity ......................................................................................................................................................... 18 kHz 60 dB
AUDIO SECTION
Continuous Power Output (8 ohms / 20 Hz - 20 kHz)
Front ........................................................................................................................................................................... 70W
Center ......................................................................................................................................................................... 70W
Surround ..................................................................................................................................................................... 70W
THD Front (20 Hz - 20 kHz) ............................................................................................................................. 8 ohms 0.09 %
Input Sensitivity/Impedance
Linear ................................................................................................................................................... 316 mV/ 47 Kohms
Signal to Noise Ratio
Linear ......................................................................................................................................................................... 99 dB
VIDEO
Input Level/Impedance ................................................................................................................................... 1 Vp-p/ 75 ohms
Output Level/Impedance ................................................................................................................................ 1 Vp-p/ 75 ohms
GENERAL
Power Requirement...........................................................................................................................
AC 100 V 50/60 Hz (F)
AC 220 V 50 Hz (K)
AC 110 V 60 Hz (L)
AC 230 V 50 Hz (N)
AC 120 V 60 Hz (U)
Power Consumption .................................................................................................................................................
170W (F)
280W (K, /N)
320W (L)
2.7A (U)
Dimension (MAX)
Width............................................................................................................................................. 17-3/8 inches (440 mm)
Height ............................................................................................................................................ 6-1/2 inches (164 mm)
Depth ............................................................................................................................................ 14-3/8 inches (365 mm)
Weight...................................................................................................................................................... 21.4 lbs (9.7 Kg)
ACCESSORIES
Remote Control Unit RC5200SR ............................................................................................................................................ 1
AAA-size batteries .................................................................................................................................................................. 2
FM Lead Type Antenna (N, /K, /L) .......................................................................................................................................... 1
FM Feader Antenna (U, /F) .................................................................................................................................................... 1
FM Antenna Converter (U, /F) ................................................................................................................................................ 1
AM Loop Antenna ................................................................................................................................................................... 1
Warranty Card (U, /F) ............................................................................................................................................................. 1
Registration Card (N) .............................................................................................................................................................. 1
User Guide ............................................................................................................................................................................. 1
AC Power Cord (N) ................................................................................................................................................................. 1
Post Card (F) .......................................................................................................................................................................... 1
Specifications subject to change without prior notice.
