9. TILT
Adjusts the voice of your Origin from
normal to high treble at the input stage.
Tilt: this control provides a blend between
normal and high treble pre-amplier
channels on a classic Marshall. Dialled all
the way to the left the sound is warm and
full, providing a thick overall tone. When
dialled all the way to the right the overall
tone is brighter for players looking for
more cut through and bite. When set at 12
o’clock the tilt control provides an equal
blend of both pre-amp voicings.
10. GAIN
Controls the amount of pre-amp gain
applied to your sound, the more gain
the more distortion. Pulling the control
knob activates a gain boost increasing the
level of drive in the pre-amp. This can be
operated using a 2-way foot switch
(PEDL-90016).
Note: when a foot switch is connected
it will override the front panel control
meaning the gain boost can only be turned
on and off using the foot switch.
ENGLISH
11. INPUT
Connect your guitar to the amplier using
a ¼” instrument cable.
ORIGIN COMBO (HEAD SHOWN ON PREVOUS PAGE)
3.0
FRONT PANEL FUNCTIONS CONTINUED
THE INFORMATION SHOWN APPLY TO BOTH 20 AND 50, HEAD AND COMBO FORMATS.
GAININPUT TREBLEMIDDLEBASS
MASTER
POWEROUTPUT
HIGH ON
MID
LOWOFF
TILT
PRESENCE
PULL BOOST
EQUALISATION OUTPUT
11
89
10 7
6
5 4 3 2 1
