Master Forge CBC23032L User Manual

5
Part Description Quantity
A Temperature Gauge 1
B Lid Handle 1
C Smoke Stack 1
D Lid 1
E Warming Rack 1
F Cooking Grid 4
G Charcoal Pan 1
H Left Side Shelf 1
I Bottom Bowl 1
J Charcoal Pan Handle 2
K Cooking Grid Handle 1
L Front Shelf 1
M Leg Brace 2
N Long Leg 2
O Short Leg 2
Part Description Quantity
P Foot* 2
Q Bottom Mesh 1
R Hub Cap 2
S Axle 1
T Wheel 2
U SFB Lid 1
V SFB Lid Handle 1
W SFB Body Top 1
X SFB Body 1
Y SFB Cooking Grid 2
Z SFB Charcoal Pan 1
AA SFB Side Handle 1
AB SFB Damper 1
* Pre-assembled
M6x12
Bolt
Qty:18
M4x10
Screw
Qty:4
M6x20
Bolt
Qty:14
M6x45
Bolt
Qty:10
Ø16x6.2
Washer
Qty:2
Ø20x10.5
Washer
Qty:2
M6
Nut
Qty:14
Ø6
Lock Washer
Qty:2
AA
BB
CC
DD EE
FF
GG
PACKAGE CONTENTS
HARDWARE CONTENTS
HH
II JJ
Ø1.4x30
Cotter Pin
Qty:4
M6
Screw
Qty:3
M8
Screw
Qty:2
#2 Philips Head
Screwdriver
Qty:1
KK
LL
