Matrix JF72553B User Manual

20
I.D Description Qte
1. Switch 1
2. Panel 1
3. Ø4 at washer 15
4. St4.2x14 screw 16
5. Overload switch 1
6. Cushion 1
7. Switch box 1
8. Label 1
9. Rubber feet 4
10. M6x25 screw 4
11. Ø6 washer 6
12. Housing 1
13. Spring piece 2
14. Block 2
15. Dustproof cover 1
16. Plug 1
17. Cable sleeve 1
18. Cable clamp 1
19. M4x10 screw 1
20. Ø4 spring washer 1
21. Spring steel clip 1
22. Block 1
23. M4 net 1
24. M4x12 screw 9
25. Dead plate 1
26. M4 net 9
27. Dead gear 1
28. M8x65 screw 1
29. Up down adjust handle 1
30. M8 net 8
31. Label 1
32. Up down adjust handwheel 1
33. Spring 1
34. Ø2.5x22 pin 1
35. Adjust bar 1
36. Ø12 spring washer 9
37. M6 net 2
38. Bracket base 1
39. Limited plate 1
40. Angle limited plate 1
41. M5x12 screw 1
42. Ø5 spring washer 5
43. Ø5 at washer 9
44. M6x85 screw 2
45. Ø6 at washer 12
46. Connecting sleeve 3
47. M6 lock net 15
48. M5x14 screw 1
49. Magnier 1
50. M8 net 2
51. Connecting hook 1
52. M8x16 screw 1
53. Lock net 1
54. Ø6 washer 1
55. Lock sleeve 1
56. M6x net 23
57. M6x30 screw 1
58. Rotary board 2
59. M6 T screw 2
60. Up down adjust bar 1
61. Bracket base 1
62. M8 T screw 2
63. Ø8 at washer 7
64. Bracket 1
65. M6x16 screw 3
66. Ø6 spring washer 9
PARTS LIST
10’’ TABLE SAW
WARNING
Any attempt to repair or replace electrical parts on this Table Saw may create a HAZARD unless repair is
done by a qualied service technician. Repair service is available at your nearest Service Centre.
