Figure C
CHAPTER 5
：
PARTS REPLACEMENT
5.3 Steel Rope
1. Disconnect the rope link to mast as section 5.2.
2. Remove the pulleys. (Figure A)
3. Remove the stopper plate. (Figure B)
4. Pull out the balance plate and disconnect the other hand of steel rope. (Figure C)
5. Reverse step 4-1 to restore.
Figure A
Figure B
Figure C
