Matrix SETU VFX Quick Start 11
Accessing Jeeves (GUI)
SETU VFX provides an embedded web server with a Graphic User Interface (GUI), Jeeves, for
configuration.
To access Jeeves, you will need to connect a computer to SETU VFX.
Connecting a Computer
You may connect a standalone computer to SETU VFX or grab any computer connected in the
same LAN as SETU VFX.
• Connect a standalone computer to SETU VFX, when installing the system for the first time. You
may connect it to the LAN after you have finished installation and configuration of the system.
• If the computer for accessing Jeeves is connected in a LAN Switch and the WAN Port of SETU
VFX is connected behind a NAT router, make sure that both the LAN and WAN connections are
in different Subnets.
To connect a standalone computer,
• Plug one end of the Ethernet cable supplied with the system into the LAN Port of SETU VFX.
Plug the other end into the LAN Port of the computer.
• Make sure the IP Address of the computer and the LAN Port of SETU VFX do not conflict, and
that both are in the same Subnet.
The default IP Address of the LAN Port of SETU VFX is: 192.168.2.100
The default Subnet Mask of the LAN Port of SETU VFX is: 255.255.255.000
