Matrix Treadmill User Manual

16
8.2) Parts List
>treadmill
MX-T5
NO. DESCRIPTION SPECIFICATION
G10
Handpulse Grip Set
M01 Motor Set
N01
Console Set
N01 Console Set-Id Line
O01 TV Bracket-USA Line (w/Cables) MATRIX T5 (TM65)
O01 TV Bracket-ID Line(w/Cables)
Q01 Front Cover Set
U01 Tension Wheel Set
002 Screw, Oval Hex Socket M6x1.0Px45L
003 TV Sleeve Nylon
005 KSS Mast Sleeve (Jacket) SB-30
006 Nylon Nut M5x0.8P
007 TV Earphone Wire 850(+RJ-45)
010 Screw, Round Head M4x0.7Px40L(15L)
011 Flat Washer 4x10x1.0t
012 Nylon Nut M4x0.7P
AB1 Frame Set
AB2 Belt Guide
AC1 Left Console Mast
AC2 Right Console Mast
AG1 Main Handle Bar
AH1 Incline Leg
AH1 TV Bracket Mend Strive Set
AN3 Console Mend Strive Set
AN4 Safety Key Set
AR1 Front Roller Set 3.5"
AR2 Rear Roller Set 3.5"
AZ1 Hardware Package
AZ2 Hardware Package (1)
AZ3 Hardware Package (2)
B35 Running Deck (Inwood) 616x1340x25.4t 3 Layers Deck
B36 Deck Cushion (SBR)
B37 Deck Cushion 30x37L(40°)
B38 Left Console Mast Base AL
B39 Right Console Mast Base AL
B40 Deck Cushion (Short A 40°)
B41 Screw, Oval Tapping 4x12L
B42 Screw, Plain Hex Socket M8x1.25Px35L
B43 Rivet (Brass Inserts Nut) ALS7-8125-3.8(0.5-3.8)
B44
Rivet (Brass Inserts Nut) ALS7-610-4.2(0.5-4.2)
B45 Screw, Round Hex Socket M8x1.25Px20L
B52 Power Switch Holder SPC
B53
Nylon Nut
M8x1.25P
NO. DESCRIPTION SPECIFICATION
B54
Screw, Oval Hex Socket M8x1.25Px20L
B55 Flat Washer 8.6x26x2.0t
B56
Spring Washer SW8 8.2x13.5x2.0t
C05 Screw, Oval Hex Socket M8x1.25Px15L
C06 Left Console Mast Cover (6~8)
C08 Right Console Mast Cover (6~8)
C09 Screw, Plain Hex Socket M8x1.25Px25L (SUS 304)
C10 Socket Head Cap Screw M8x1.25Px20L
C11 Screw, Round Head M5x0.8Px8L
C13 Flat Washer 8.2x16x1.4t
G07 Handlebar Casing Pipe G20%
G08 Heart Rate Sensor Plate
G09 Upper End Cap For Grip Pulse
G10 Pulse Sensor
G12 Lower End Cap For Grip Pulse
G13 Handlebar Mend Strive Pipe 25.4x1.5tx208L
G14 Handlebar Mend Strive Pipe End Cap POM
G15 Spring
G19 Screw, Oval Head M5x0.8Px12L
G20 Screw, Round Head M3x12L
G23 Spring Washer SW6 6.0x10.0x1.5t
H08 Axle Bushing
H09 Plastic Plug AC002
H10 Bolt, Round Hex Socket M12x1.75Px70L
H11 Flat Washer 12.7x23x2.2t
H12 Cap 45x45
H13 Nylon Nut M12x1.75P
H14 Wave Washer 20.7x29.1x0.3t
H15 Spring Washer SW12 12.2x21.5x3t
L01 Mobile Wheel
L02 Flat Washer 8.2x30x2.0t
L03 Screw, Oval Hex Socket M8x1.25Px12L
M02 Incline Motor (110V) 1100LB/115V 124mm T4/T5
M03 Motor Fixing Plate
M05 Motor Control Board MD65 5HP/230V (Reliance)
M07 Dcrew, Hex Head M12x1.75Px55L(30L)
M10 Nylon Nut M12x1.75P
M11 Connecting Cable For Incline Motor
M12 Screw, Oval Hex Socket M8x1.25Px25L
M13
Nylon Nut M8x1.25P
M14 Screw 3/8"-16UNCx25L (BED)
M15 Nylon Nut 3/8"-16UNC
M16
Flat W
asher 8.2x20x1.8
