Fuses
Your vehicle' s electrical system is
protected by fuses.
If any lights, accessories, or controls don't
work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.
If the same fuse blows again, avoid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
qFuse Replacement
Replacing the fuses on the driver's side
If the electrical system doesn't work, first
inspect fuses on the driver's side.
1. Turn off the ignition switch and other
switches.
2. Open the fuse panel cover.
Fuse panel cover
3. Pull the fuse straight out with the fuse
puller provided on the inside of the
cover for the fuse panel and the fuse
block cover inside of the engine
compartment.
4. Inspect it and replace if it's blown.
Normal
Blown
5. Push in a new fuse of the same
amperage rating, and make sure it fits
tightly. If it doesn't, have an Authorized
Mazda Dealer install it.
If you have no spare fuses, borrow one
of the same rating from a circuit not
essential to vehicle operation, such as
the ROOM circu it.
8-40
Maintenance and Care
