Black plate (259,1)
l
Amount of airflow
l
Selection of airflow mode
OFF switch
Pressing the OFF switch shuts off the
climate control system.
Temperature control switch
This switch controls temperature. Press
for hot and for cold.
Fan control switch
The fan has five speeds.
Mode selector switch
The desired airflow mode can be selected
(page 6-13).
qOperation of Automatic Air
Conditioning
Operation from front seats
1. Turn the front air conditioning on.
2. Press the rear switch. The rear air
conditioning operates.
3. Selection of the airflow mode, airflow
amount and temperature will be
automatically controlled to the same
temperature setting as the front air
conditioner for the driver's side.
Interior Comfort
Climate Control System
6-15
CX-9_8AU3-EC-09G_Edition1 Page259
Monday, July 13 2009 7:10 PM
Form No.8AU3-EC-09G
