5. Pull it out again.
The proper fluid level is marked on the
dipstick as follow s.
A
B
Full
Low
Full
Low
Fluid hot scale A
When the vehicle has been driven and the
fluid is at normal operating temperat ure,
about 65 °C (150 °F), the level must be
between Full and Low.
Fluid cold scale B
When the engine has not been running
and the outside temperature is about 20 °C
(70 °F), the fluid level should be close to,
but not above, the bottom notch on the
dipstick.
CAUTION
Ø Use the cold scale only as a
reference.
Ø If outside temperature is lower
than about 20 °C (70 °F), start the
engine and inspect the fluid level
after the engin e reaches operating
temperature.
Ø If the vehicle has been driven for
an extended period at high speeds
or in city traffic in hot weather,
inspect the level only after
stopping the engine and allowing
the fluid to cool for 30 minutes.
Fully insert the dipstick. When adding
fluid, inspect with the dipstick to make
sure it does not pass full.
NOTE
Inspect the fluid on both sides of the dipstick in
a well lit area for an accurate reading.
Maintenance and Care
Owner Maintenance
8-25
