McCulloch ERGOLITE 6028 User Manual

MAINTENANCE
18 – English
Cleaning and lubrication
Clean any resin and plant residue from the blades using
cleaning agent 531 00 75-13 (UL22) before and after
using the machine.
Check that the blade edges are not damaged or
deformed. File away any burrs.
Check that the blades move freely. Remove the
lubrication plug in the gear housing and stick in the
combination spanner and turn back and forth.
Lubricate the blade bars with special grease, part no. 531
00 75-12 (UL 21) before long periods of storage.

McCulloch ERGOLITE 6028 Specifications

General

Blade size	600 mm
Blade type	Double blade
Cutting rate	7800 RPM
Product color	Black, Yellow
Handle(s) features	Adjustable
Vibration emission	4.1 m/s²
Blade tooth spacing	28 mm
Sound pressure level	101 dB
Cutting thickness (max)	20 mm
Fuel tank capacity	0.3 L
Engine displacement	21.7 cm³
Motor rotation speed	9000 RPM
Engine power	600 W
Power source	Gasoline

Weight and Dimensions

Weight	5000 g
