10
Specifications
Specifications
Power Output Per Channel
160 watts into 4 or 100 watts into 8 ohm loads is the mini-
mum sine wave continuous average power output per chan-
nel both channels operating.
Power Output Bridged
500 watts into 4 ohms or 320 watts into 8 ohm loads is the
minimum sine wave continuous average power output.
Output Load Impedance
4 or 8 ohms
Rated Power Band
20Hz to 20,000Hz
Dynamic Headroom
1.6dB
Frequency Response
+0, -0.25dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Total Harmonic Distortion
0.005% maximum at any power level from 250 milliwatts
to rated power per channel from 20Hz to 20,000Hz, both
channels operating.
Intermodulation Distortion
0.005% maximum if instantaneous peak output per channel
does not exceed twice the rated output with both channels
operating for any combination of frequencies from 20Hz to
20,000Hz.
Signal To Noise Ratio
110dB below rated output
Sensitivity
.9 volts (2.0V at level control center detent position)
Input Impedance
10,000 ohms Unbalanced
22,000 ohms Balanced
Damping Factor
Greater than 100 at 4 ohms
Greater than 200 at 8 ohms
Power Requirements
100 Volts, 50/60Hz at 6.0 amps
110 Volts, 50/60Hz at 5.45 amps
120 Volts, 50/60Hz at 5.0 amps
220 Volts, 50/60Hz at 2.7 amps
230 Volts, 50/60Hz at 2.6 amps
240 Volts, 50/60Hz at 2.5 amps
NOTE: Refer to the rear panel of the MC162 for the correct
voltage
Dimensions
Front Panel: 17/1/2 inches (44.5cm) wide, 5-3/8 inches
(13.7cm) high. Depth behind front mounting panel is 18 1/
2 inches (47cm) including clearance for connectors. Panel
clearance required in front of mounting panel is 1-1/8
inches (2.9cm).
Weight
42 pounds (19.1 Kg) net, 60 pounds (27.2 Kg) in shipping
carton
