McIntosh MC2301 User Manual

23
Packing Instructions
Quantity Part Number Description
1 034105 Shipping carton top
1 034104 Shipping carton bottom
2 034439 Foam Pad (top and bottom)
3 034441 Foam Ring
2 034440 Foam Inserts (for protecting
the Tubes during shipping)
1 0410900 Warning Sheet
4 400159 10-32 x 3/4 inch screw
4 018445 Feet
Packing Instructions
In the event it is necessary to repack the equipment for
shipment, the equipment must be packed exactly as shown
below. It is very important that the four feet are attached to
the bottom of the equipment. This will ensure the proper
equipment location on the bottom foam pad. Failure to do
this will result in shipping damage.
To protect the tubes during shippment, the two Foam
Inserts removed from the MC2301 need to be re-inserted.
Follow the unpacking instructions on pages 3-4 in the
reverse order.
Use the original shipping carton and interior parts only
if they are all in good serviceable condition. If a shipping
carton or any of the interior part(s) are needed, please
call or write Customer Service Department of McIntosh
Laboratory, refer to page 3. Please see the Part List for the
correct part numbers.
WARNING
SHEET
FOAM
INSERT
FOAM
INSERT
TUBE
COVERS

McIntosh MC2301 Specifications

General

Damping factor	15
Amplifier class	-
Frequency range	10 - 100000 Hz
Output impedance	8 Ω
Audio output channels	1.0 channels
Peak power per channel	300 W
Signal-to-Noise Ratio (SNR)	117 dB
Total Harmonic Distortion (THD)	0.5 %
Speakers connectivity type	Binding post
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	50 - 60 Hz
LED indicators	Yes

Weight and Dimensions

Depth	584.2 mm
Width	450.9 mm
Height	312.7 mm
Weight	52600 g
