SPECIFICATIONS
POWER OUTPUT
500 watts per channel into an 8, 4 or 2
ohm load is the minimum sine wave con-
tinuous average power output
1000 watts Mono into a 16, 8 or 4 ohm
load is the minimum sine wave continuous
average power output
RATED POWER BAND
20Hz to 20,000Hz
TOTAL HARMONIC DISTORTION
0.005% maximum harmonic distortion at
any level from 250 milliwatts to rated power
output
DYNAMIC HEADROOM
2.1dB
FREQUENCY RESPONSE
+ 0, -0.25dB from 20Hz to 20,000Hz
+ 0, -3.0dB from 10Hz to 100.000Hz
INPUT SENSITIVITY
2.2 volts, Stereo Balanced and
Unbalanced
2.2 volts, Mono Balanced
3.2 volts, Mono Unbalanced
A-WEIGHTED SIGNAL-TO-NOISE RATIO
85dB (115dB below rated output)
INTERMODULATION DISTORTION,
SMPTE
0.005% maximum if instantaneous peak
power output does not exceed twice the out-
put rating
WIDE BAND DAMPING FACTOR
200 at 8 ohm output
INPUT IMPEDANCE
10,000 ohms
POWER GUARD
Clipping is prevented and THD does not
exceed 2% with up to 14dB overdrive at
1000HZ
POWER REQUIREMENTS
120 volts. 50/60Hz, 12 amperes UL/CSA
SIZE
17-1/4 inches (43.8cm) W, 10-3/8 inches
(26.4cm) H, 20-1/3 inches (51.1cm) D. in-
cluding front handles
WEIGHT
114 pounds (51.7Kg) net, 127 pounds
(57.6Kg) shipping
14
