The MCD600 Power Control Circuitry provides an
internally generated Power Control Signal for exter-
nally connected Power Amplifier.
The connection instructions below, together with
the MCD600 Connection Diagram located on the
separate folded sheet “Mc1B” is an example of using
the MCD600 as a Preamplifier with built-in Disc and
Digital Data Player. Your system may vary from this,
however the actual components would be connected in
a similar manner. For additional information refer to
“Connector and Cable Information” on page 4.
Power Control Connections:
1. Connect a Control Cable from the MCD600 POW-
ER CONTROL Out Jack to the Power Control In
Jack on the Power Ampifier.
2. Optionally, connect a Control Cable from the
Power Amplifier Power Control Out 1 Jack to
additional McIntosh components with a Power
Control In Jack.
Audio Connections:
3. Connect a XLR Audio Cable from the MCD600
VARIABLE AUDIO BALANCED OUTPUTS to
the Power Amplifier Balanced Input connectors.
Note: The UNBALANCED Output Jacks may be
used instead of the BALANCED Connection.
AC Power Cords Connections:
4. Connect the McIntosh MCD600 SACD/CD Trans-
port AC Power Cord to a live AC outlet.
Connections to Power Amplifier
Connections to Power Amplifier
To Next Page
