Wiring Diagram
Configuration Mode
The configuration mode is used to set the McQuay 668811101 thermostat to match your heating/cooling system.
The McQuay 668811101 thermostat functions with heat pump, air conditioning, gas, oil or electric heat systems.
1. To enter the configuration mode, simultaneously hold down the and buttons while
the McQuay 668811101 thermostat is in OFF mode.
2. Press the or button to change settings within each screen.
3. Press the PROGbuttontoadvancetothenextscreen.
Note: The MODE button will return you to the previous screen.
4. Toexitcongurationmode,holdthePROG button for 6 seconds.
2. Differential(1°F-5°F)(1°C-3°C)–Setthenumberofdegreesbetweenyour“turnon”
temperatureandyour“setpoint”temperature.
Press the or button to set differential value.
Press the PROGbuttontoadvancetothenextscreen.
3. Deadband(1°F-9°F)(1°C-5°C)–Settheminimumnumberofdegreesbetween
your heating system activation and your cooling system activation.
Press the or button to set deadband value.
Press the PROGbuttontoadvancetothenextscreen
1. Temperaturescale(ForC)–ChooseFahrenheitorCelsius.
Press the or button to select.
Press the PROGbuttontoadvancetothenextscreen.
Configuration Mode Settings
4. Heat pump – Press the or button to configure as heat pump, or non-heat pump
system.
 •ON=Heatpumpsystem–4minutetimedelaywithheatandcool
 •OFF=Non-heatpumpsystem–4minutetimedelaywithcoolonly
Press the PROGbuttontoadvancetothenextscreen
5. Lockout(0-8°,NITE,COOL-HEAT)–Selectthenumberofdegreessettemperature
can be changed during keypad lockout or select to lockout during NITE period only.
COOL-HEATlockoutallowsadjustmentofthesettemperaturestothemaximumheatset
temperature selected in Step 6 and minimum cool set temperature selected in Step 7.
Note: The mode cannot be changed when the thermostat is locked.
Press the or button to select.
Press the PROGbuttontoadvancetothenextscreen
6. MaximumHeatSetpoint(45°F-90°F)(7°C-32°C)
 Adjusttocontrolthemaximumheatsettemperatureallowed.
Press the or button to select.
Press the PROGbuttontoadvancetothenextscreen
7. MinimumCoolSetpoint(45°F-90°F)(7°C-32°C)
Adjust to control the minimum cool set temperature allowed.
Press the or button to select.
Press the PROGbuttontoadvancetothenextscreen
ON
Starting the Thermostat
8. Roomtemperatureoffset(+9°Fto-9°F)(+5°Cto-5°C).
Adjust to calibrate displayed room temperature to match actual room temperature.
Press the PROGbuttontoadvancetothenextscreen.
9. Maximumcompressorcyclesallowedperhour(d,2-6).
 ––=asmanyasneeded,2-6=maximumcycles/hour
Press the PROGbuttontoadvancetothenextscreen.
10. Statusindicatorlight(ON,OFF).
Press the or button to select.
 Toexitcongurationmode,pressthePROG button for 6 seconds.
Note: First button press activates backlight only.
1. Move the Fan Auto/On switch to the Auto position.
2. Press the MODE button to enter desired operating mode.
3. Press PROG to select program or non-program option.
Testing the Thermostat
Once the thermostat is installed, it should be thoroughly tested.
Cool Test
1. Press mode button until cool mode is displayed.
2. Adjust set temperature so it is 5 degrees below room temperature.
3. Air conditioning should come on. Green LED turns ON.
4. Adjust the set temperature 2 degrees above the room temperature and the A/C should
turn off. There may be a fan delay on your system.
Note: There is a four-minute time delay to protect the compressor after it turns off.
Heat Test
1. Press mode button until heat mode is displayed.
2. Adjust the set temperature so it is 5 degrees above the room temperature.
3. Heat should come on. Red LED turns ON.
4. Adjust the set temperature 2 degrees below the room temperature and the heat
should turn off. There may be a fan delay on your system.
Note: For heat pumps, there is a four-minute delay to protect your compressor.
Fan Test
1. Slide fan switch to ON position. Indoor fan turns ON.
2. Slide fan switch to Auto position. Indoor fan turns OFF.
Mode of Operation
The McQuay 668811101 thermostat is a programmable, auto changeover, single stage heat, single stage cool
thermostat. It functions with air conditioning, heat pumps, gas, oil or electric heat systems.
The thermostat activates the heating appliance when the room temperature is below the set heat temperature
(bythedifferentialtemperature)andtheredindicatorlightonthethermostatwilllight.TheMcQuay668811101
thermostat will stop outputting and the red light will turn off when the call for heat has been satisfied. With heat
pumps, the thermostat will not let the compressor come on for 4 minutes after it turns off. This protects your
compressor.
Whentheroomtemperatureisgreaterthanthesetcooltemperature(bythedifferentialtemperature),thecooling
device is activated and the green indicator light on the thermostat will turn on. The McQuay 668811101 thermostat
will stop outputting and the green light will turn off when the call for cooling is satisfied. The thermostat will not let the
compressor come on for 4 minutes after it turns off. This protects your compressor.
The McQuay 668811101 thermostat has five possible operating modes: OFF, Heat, Cool, Heat & Cool and Program
mode. In off mode, the thermostat will not turn on heating or cooling devices. The manual fan can be turned on in
all operating modes using the fan switch and the fan speed can be set in all operating modes using the fan speed
switch. In heat mode, the thermostat controls the heating system. In the Cool mode, the thermostat controls the
cooling system. In heat & cool mode, the thermostat controls both the heating and cooling systems. In program
mode, the thermostat will automatically be controlled by the set program. Program mode can function with heat
mode, cool mode or heat & cool mode. The clock display alternates with the set temperature display for heat & cool
mode.
Theprogramschedulecanbeoverriddenbychangingthesettemperature( or button).ThisputstheMcQuay
668811101 thermostat thermostat into a 2 hour temporary hold. After 2 hours, it will automatically return to the
program schedule.
The McQuay 668811101 thermostat also has a button lockout feature. This enables the thermostat to be set to the
proper mode and temperature and locked so it cannot be tampered with.
Setting the Time and Day of the Week
The time and day of the week must be set for your program schedule to operate correctly.
1. Press the MODE button until you are in the OFF mode.
2. Press the PROG button in for 6 seconds. Time displays.
3. Press the or button to adjust the time.
4. Press the PROG button while the time is displayed. The display shows the day
currentlysetonthethermostat(1=Monday,2=Tuesday,etc).
5. Press the or button to set the correct day of the week that today is.
Note: Press the PROG button in for 5 seconds to lock values into memory
and return to the OFF mode or press the PROG button once to
enter programming.
 •Settimeisdisplayed
8. Press the or button to change set time.
9. Press the PROG buttontoadvancetothenextscreen.
Note:Transitionsrequiredafter11:59PMmustbeprogrammedinthenextday’s
MORN transition.
 •Heattemperatureisdisplayed(45°Fto90°F)
10. Press the or button to adjust heat set temperature.
11. Press the PROGbuttontoadvancetothenextscreen.
 •Cooltemperatureisdisplayed(45°Fto90°F)
Note: Cool cannot be set lower than heat temperature.
12. Press the or button to adjust cool set temperature.
13. Press the PROGbuttontoadvancetothenextscreen.
Repeat steps 1-13 to program each day of the week individually or use the Simpleset
®
feature(seePage14)toprogrameverydaythesameasMonday.
When programming is complete, press and hold the PROG button in for 5 seconds to return to the OFF mode.
PROG must display on the screen for the thermostat to follow the program schedule. If PROG does not appear,
press the PROG button until PROG displays.
Programming
Program Overview
TheMcQuay668811101thermostatprogrammablethermostathasfourperiods(MORN,DAY,EVE,NITE)thatare
customizable for each day of the week. Each period will have a start time, heat temperature, and cool temperature.
The McQuay 668811101 thermostat monitors the day and time, while maintaining the specific conditions you have
chosen for each period in your program.
1. Press the MODE button until you are in the OFF mode.
2. Press the PROG button for 6 seconds.
3. Press the PROG button twice.
•Dayisdisplayed(1-7)
4. Press the or button to change the day you want to program
(1=Monday,2=Tuesday,etc.).
5. Press the PROG buttontoadvancetothenextscreen.
Note: You can always press the MODE button to return to the
previous parameter.
•Periodisdisplayed(MORN,DAY,EVE,NITE)
6. Press the or button to change period of day.
7. Press the PROG buttontoadvancetothenextscreen.
6-Wire,
MORN
DAY EVE NITE
HEAT HEAT HEAT HEAT
COOL COOL COOL COOL
MONDAY
1
MORN DAY EVE NITE
HEAT HEAT HEAT HEAT
COOL COOL COOL COOL
TUESDAY
2
MORN DAY EVE NITE
HEAT HEAT HEAT HEAT
COOL COOL COOL COOL
WEDNESDAY
3
MORN 6:00 AM DAY 8:00 AM EVE 6:00 PM NITE 10:00 PM
HEAT
70°F
HEAT
62°F
HEAT
70°F
HEAT
62°F
COOL
78°F
COOL
85°F
COOL
78°F
COOL
82°F
MONDAY
thru
SUNDAY
Personal Program Schedule
Factory Preprogramming
The McQuay 668811101 thermostat comes preprogrammed with the following schedule:
Usethefollowingpersonalprogramscheduletorecordyoursettings:
Simpleset® Programming
Lockout Function
AfterthecompleteMondayscheduleisset(seeProgrammingonPage12),youareattheDay2screen:
1. Press the button once. Day 1 screen displays.
2. Press and hold the button for 3 seconds.
• Thedaysoftheweekwillcountdownfrom7to1andthiswilllockthe
settings into memory.
• Oncethescheduleislockedin,youcangothrougheachdayandmake
any changes you require. This feature speeds up the programming of
the standard weekday/weekend schedule.
3. Press and hold the PROG buttonfor5secondstoexitprogrammodeand return to the OFF mode.
The McQuay 668811101 thermostat thermostat has a button lockout feature so the settings cannot be
changedortamperedwith.Withthelockoutactivated,anybuttonpresswillresultin“LOC”beingdisplayed.
To activate the LOC function:
1. Press the MODE button and hold it in.
2. Also press the PROG button and keep both depressed for 10 seconds.
3. LOC will display and all buttons will be disabled.
To deactivate the LOC feature, repeat steps 1 & 2 above.
Simpleset
®
programmingisaconvenientmethodofprogrammingthethermostat.OncetheentireMonday(Day1)
schedule is set, Simpleset
®
programming will copy the Monday schedule to every day of the week.
Operating Modes
TherearesixpossibleoperatingmodesfortheMcQuay668811101thermostat.Off,Cool,Heat,andCool&Heat
modes are accessed by pressing the Mode button. Program mode is accessed by pressing the Prog button. Continuous
fan mode is accessed by setting the auto/on switch to ON.
Cool and Heat Mode (Auto Changeover) – In this mode, the thermostat controls
the cooling and heating systems, automatically changing over from one to the other as
needed.
Program Mode–Inthismode,theprogramfunctionison(PROGdisplays),andthe
thermostat will automatically be controlled by the set program schedule. Program mode can
function with heat mode, cool mode or heat & cool mode. The program schedule can be
overriddenbychangingthesettemperature( or button).After2hours,theprogram
schedule will automatically be resumed. To manually return to the program schedule, press
the PROG button twice.
Cool Mode
•Inthismode,thethermostatcontrolsthecoolingsystem
Note: There is a four minute delay for your compressor to restart after it has turned off.
Heat Mode
•Inthismode,thethermostatcontrolstheheatingsystem
Note: For heat pumps, there is a four minute delay for your compressor to restart after
it has turned off.
OFF Mode
•Inthismode,thethermostatwillnotturnontheheatpump.
Continuous Fan Mode
•Theindoorfancanbeturnedonmanuallyineveryoperatingmodebyslidingtheauto/onswitchtoON.
CAUTION
Do not energize the air conditioning system when the outdoor temperature is below 50 degrees.
It can result in equipment damage or personal injury.
