McQuay MAC 100 C User Manual

Technical Data
Water Pressure Drop
MAC/M4AC080C/CR
Flowrate
(m3/hr)
Pressure drop
(psig)
BPHE
(kPa)
Pump head
(kPa)
Hydraulic life
(kPa)
Unit Water
Piping (psig)
Unit Pressure
Drop (psig)
Total Pressure
Drop (kPa)
2.4 2.0 14 300 2,81 0.7 2.7 18.7
3.2 3.6 25 270 237 1.1 4.7 32.6
4 5.5 38 260 211 1.7 7.2 49.3
4.8 7.8 54 230 160 2.3 10.1 69.6
5.6 10.6 73 200 106 3.0 13.6 93.5
6.4 13.8 95 175 54 3.8 17.6 121.0
MAC/M4AC100C/CR
Flowrate
(m3/hr)
Pressure drop
(psig)
BPHE
(kPa)
Pump head
(kPa)
Hydraulic lift
(kPa)
Unit Water
Piping (psig)
Unit Pressure
Drop (psig)
TotaL Pressure
Drop (kPa)
3 2.3 16 280 257 1.0 3.3 22.9
4 4.1 28 260 221 1.7 5.7 39.3
56.243220160 2.4 8.7 59.8
6 8.8 61 180 96 3.4 12.2 84.2
7 11.9 82 150 37 4.5 16.3 112.6
MAC/M4AC120C/CR
Flowrate
(m3/hr)
Pressure drop
(psig)
BPHE
(kPa)
Pump head
(kPa)
Hydraulic lift
(kPa)
Unit Water
Piping (psig)
Unit Pressure
Drop (psig)
Total Pressure
Drop (kPa)
3 1.4 9.7 280 263 1.0 2.4 16.6
4 2.5 17 270 241 1.7 4.1 28.6
5 3.8 26.4 260 216 2.5 6.3 43.6
6 5.5 37.7 250 188 3.5 8.9 61.5
7 7.4 51 230 148 4.6 12.0 82.4
MAC/ M4AC150C/CR
Flowrate
(m3/hr)
Pressure drop
(psig)
BPHE
(kPa)
Pump head
(kPa)
Hydraulic lift
(kPa)
Unit Water
Piping (psig)
Unit Pressure
Drop (psig)
Total Pressure
Drop (kPa)
3 1.0 6.9 280 266 1.0 2.0 13.8
4 1.8 12.1 270 246 1.7 3.4 23.7
5 2.7 18.8 260 224 2.5 5.2 36.0
6 3.9 26.9 250 199 3.5 7.4 50.7
7 5.3 36.4 230 162 4.6 9.8 67.8
8 6.9 47.3 210 123 5.8 12.6 87.1
46
