IM 1128-2 33
Dimensions and Weights
Type I
The following table gives the dimensions and weight of the chiller with the compressor and starter/VFD
removed and the dimensions and weight of the shipped-loose compressor.
NOTE: The height dimension shown in Table 1 for “Chiller w/o Compressor” is to the top of the control panel.
Further height reduction can be achieved by removing the panel. Consult the local McQuay International sales
office for details.
Table 1, Type I, Dimensions & Weights
Unit Size
Vessel Code
Chiller w/o Compressor
Compressor
Unit Width
Unit Height
Unit Weight
Width
Height
Weight
063
E2009 / C1809
57.1 (1450.6)
61.6 (1564.4)
5212 (2366)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2209 / C2009
57.1 (1450.6)
64.0 (1624.8)
5919 (2687)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2209 / C2209
57.1 (1450.6)
64.0 (1624.8)
6216 (2882)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2609 / C2209
57.1 (1450.6)
67.5 (1715.0)
7048 (3200)
44.0 (1118.6)
25.1 (638.3)
2000 (908))
063
E2609 / C2609
57.1 (1450.6)
73.1 (1857.8)
7784 (3534)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E3009 / C2609
56.8 (1441.7)
75.7 (1922.0)
9692 (4400)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2012 / C1812
57.1 (1450.6)
61.6 (1564.4)
6084 (2762)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2212 / C2012
57.1 (1450.6)
64.0 (1624.8)
6982 (3170)
44.0 (1118.6)
25.1 (638.3)
2000 (908))
063
E2212 / C2212
57.1 (1450.6)
64.0 (1624.8)
7357 (3340)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2612 / C2212
57.1 (1450.6)
67.5 (1715.0)
8377 (3803)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E2612 / C2612
57.1 (1450.6)
73.1 (1857.8)
9294 (4219)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
063
E3012 / C2612
56.8 (1441.7)
75.7 (1922.0)
10703 (4859)
44.0 (1118.6)
25.1 (638.3)
2000 (908)
079
E2209 / C2209
50.2 (1274.6)
62.3 (1581.7)
6940 (3151)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E2609 / C2209
52.7 (1338.3)
63.9 (1622.8)
7780 (3532)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E2609 / C2609
52.7 (1338.3)
69.5 (1765.6)
8516 (3866)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E3009 / C2609
57.1 (1449.8)
74.0 (1878.6)
9692 (4400)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E3009 / C3009
59.0 (1499.4)
79.4 (2016.8)
10876 (4938)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E3609 / C3009
74.7 (1896.1)
78.8 (2001.0)
12713 (5772)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E2212 / C2212
50.2 (1274.6)
62.3 (1581.7)
8081 (3669)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E2612 / C2212
52.7 (1338.3)
63.9 (1622.8)
9109 (4135)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E2612 / C2612
52.7 (1338.3)
69.5 (1765.6)
10026 (4552
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E3012 / C2612
57.1 (1449.8)
74.0 (1878.6)
11435 (5191)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E3012 / C3012
59.0 (1499.4)
79.4 (2016.8)
12919 (5865)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
079
E3612 / C3012
74.7 (1896.1)
78.8 (2001.0)
15140 (6874)
43.6 (1108.2)
25.1 (638.3)
3200 (1452)
Continued on next page.
