30 IM 1128-2
Type III Reassembly
Description
TYPE III: The unit ships fully assembled and is field ready to knockdown. Included are the vessel
bolt-on connection brackets, the discharge stack bolt-on flanges at the condenser and the bolt-on oil
pump assembly.
1. The unit is shipped fully charged with refrigerant and lubricant.
2. The unit will be factory insulated and painted.
3. All electrical and sensor wiring will be fastened as usual.
4. The starter will ship per order instructions.
5. Touch up paint and stick on wire ties will be included.
6. This unit will be fully tested at the factory.
7. Labels will be provided with the instructions to mark piping, electrical wiring and sensor wiring.
Reassembly Steps
Type III units offer a variety of disassembly opportunities. In some cases the condenser and tube
support plate are removed to meet narrow entrance requirements. Sometimes the compressor and unit
control panel are removed for low height situations. Other possibilities exist.
Therefore it is difficult to prescribe step-by-step procedures. Various sections of this manual can be
used where applicable, bearing in mind that the unit is fully charged with refrigerant and lubricant.
