OV00.01-S-1001-28VA Abbreviations of signal and circuit designations
for wiring diagrams
Abbreviation Designation Notes
(+) Positive
(
-
) Negative
15 Switched positive
30 Battery voltage, positive (continuous positive)
31 Return line to battery negative or ground, direct
49 Turn signal generator input
49a Turn signal generator output
49L Left turn signal lamp
49R Right turn signal lamp
50 Starter control (direct)
55 Front fog lamp
56 Headlamp light
56a High beam and high beam indicator
56b Low beam
58 Position, tail, license plate and instrument lamps
58d Variable instrument/switch illumination
61 Alternator monitor
85 Negative or ground winding end
86 Start of winding
87 Input
87a First output (NC side)
87b Second output
87c Third output
A-CDW-SIG CD-player with changer signal
Copyright DaimlerChrysler AG 03.12.2005 CD-Ausgabe G/11/05 . This WIS print-out will not be recorded by Modification services. Page 1
