Installing Outboard
BOAT TRANSOM HEIGHT REQUIREMENT
Measure the transom height of your boat. The anti‑ventilation plate should be
25–50 mm (1–2 in.) below the bottom of the boat.
a - Anti‑ventilation plate
INSTALLING OUTBOARD ON TRANSOM
1. Place outboard on centerline of transom.
27005
2. Tighten transom clamp handles.
28377
a
28376
INSTALLATION
eng 13
