Fluid
Ford Part
Name
Application Capacity
Power Transfer
Unit
Motorcraft SAE
75W-140 High
Performance
Synthetic Rear
Axle Lubricant
4X4
12 ounces
(0.35L)
Engine coolant
3
Motorcraft
Premium Gold
Engine Coolant
(yellow-colored)
2.3L I4 engine
6.3 quarts
(6.0L)
3.0L V6 Duratec
engine
10.6 quarts
(10.0L)
Rear axle
lubricant
Motorcraft SAE
80W-90
Premium Rear
Axle Lubricant
4X4
2.96 pints
(1.4L)
4
Windshield
washer fluid
Motorcraft
Premium
Windshield
Washer
Concentrate
All
2.7 quarts
(2.6L)
1
Ensure the correct automatic transmission fluid is used.
Transmission fluid requirements are indicated on the dipstick
blade. MERCON威 and MERCON威 V are not interchangeable. DO
NOT mix MERCON威 and MERCON威 V. Refer to your scheduled
maintenance information to determine the correct service
interval.
2
Indicates only approximate dry-fill capacity. Some applications may vary
based on cooler size and if equipped with an in-tank cooler. The amount
of transmission fluid and fluid level should be set by the indication on
the dipstick’s normal operating range.
3
Add the coolant type originally equipped in your vehicle.
4
Fill to 1/4 inch to 9/16 inch (6 mm to 14 mm) below bottom of fill hole.
5
Use of synthetic or synthetic blend motor oil is not mandatory. Engine
oil need only meet the requirements of Ford specification
WSS-M2C930-A and the API Certification mark.
2006 Mariner (mrn)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
263
