Mercury 2009 Mariner User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
13 10A* A/C clutch
14 15A* Trailer tow turn lamps
15 — Not used
16 40A** Cooling fan 1
17 40A** Cooling fan 2
18 20A** ABS solenoid
19 30A** Power seats
20 — A/C clutch relay
21A — Rear defroster relay
21B — Fuel relay
21C — Blower relay
21D — PCM relay
22 20A* Fuel pump
23 15A* Fuel injectors
24 — Not used
25 5A* Anti-lock Brake System (ABS)
26 15A* Ignition coils
27 10A* PCM non mil-malfunction
indicator lamp
28 20A* PCM mil-on malfunction indicator
lamp
29 15A* Powertrain Control Module
30A — Cooling fan 1 relay
30B — Starter relay
30C — Cooling fan main relay
30D — Cooling fan 2 relay
31A — Reverse lamp relay
31B — Not used
31C — Trailer tow left turn relay
31D — Trailer tow right turn relay
31E — Trailer tow park relay
