Stowing the jack and tools
• Make sure the jack is fully
lowered.
• Reclip the tools onto the jack
making sure that the tools are
fully contained by the clips as
shown.
• Reinstall the jack in the pocket
with the left side first, then snap
the right side down.
• Ensure that the hold-strap
contains the jack and tools before snapping the buckle.
• Ensure that the jack and tools are oriented as illustrated.
Stowing the flat/spare tire
Note: Failure to follow spare tire stowage instructions may result in
failure of cable or loss of spare tire.
If you are stowing a tire that requires reattaching it to the
vehicle with a tether, perform these steps first, then proceed with
the steps following.
1. Place tire on end with valve stem
facing rearward, away from vehicle.
2. Place tether into bolt holes in
wheel and attach lug nut using lug
wrench.
3. Lay the tire on the ground with the valve stem facing down. If your
vehicle is equipped with aluminum wheels, remove the wheel ornament.
4. Slide the wheel partially under the vehicle and install the retainer
through the center of the wheel.
5. Turn the jack handle clockwise until the tire is raised to its original
position underneath the vehicle. The effort to turn the jack handle
increases significantly as the tire contacts the frame. The spare tire
carrier will ratchet when the tire is in the fully stowed position. The
2009 Mariner (mrn)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
240
