Mercury 25 Series User Manual

GENERAL INFORMATION
28
1 - Tilt handle
2 - Upper cowl
3 - Water pump indicator hole
4 - Water plug
5 - Reverse Lock Lever
6 - Drive shaft housing
7 - Anti‑ventilation plate
8 - Trim tab
9 - Secondary water intake
10 - Propeller
11 - Starter rope handle
12 - Shift lever
13 - Throttle grip
14 - Clamp screw
15 - Clamp bracket
16 - Trim position pin
17 - Upper oil plug
18 - Cooling water intake
19 - Lower oil plug
20 - Connector B
21 - Stop switch
22 - Choke knob
23 - Fuel tank
24 - Primer valve
25 - Fuel connector
26 - Fuel tank cap
27 - Air vent screw
28 - Fuel Pick Up Elbow
