INSTALLATION MANUAL
90-864198020 Page 69 of 77
Refer to gauge manufacturer’s instructions for specific connections.
NOTE:
1
Connect Wires Together with Screw and Hex Nut; Apply Liquid Neoprene to Con-
nection and Slide Rubber Sleeve over Connection.
NOTE:
2
Power for a Fused Accessory Panel May Be Taken from This Connection. Load
Must Not Exceed 40 Amps. Panel Ground Wire Must Be Connected to Instrument Terminal
That Has an 8-Gauge BLACK (Ground) Harness Wire Connected to it.
NOTE:
3
Taped back BROWN-WHITE wire may be used for an accessory. LOAD MUST
NOT EXCEED 5 AMPS.
a-Audio Warning Buzzer
b-Tachometer
c-Oil Pressure
d-Water Temperature
e-Battery Meter
f-Ignition Switch
g-Read/Observe NOTE
1
h-Read/Observe NOTE
1
and
2
.
i-Read/Observe NOTE
3
.
j-To Engine Wiring Harness
To Next Page
