Mercury Regatta Part code: Z40960 (Rev A)
Owner’s Handbook Page 9 of 20
4. Operation
3 4 5 6 721 8
4.1 Control Panel
1. Wigwag Paddle
2. Head Light / Rear Light Switch
3. Indoor / Outdoor Switch
4. Battery Gauge
5. Speed Dial
6. Indicator Switch
7. Hazard Warning Light Switch
8. Horn Button
4.2 How To Operate Your Scooter
• Ignition Switch
Use the ignition switch located on the tiller head to switch the scooter on and off. Insert the key in
to the ignition and turn the key 90º clockwise to switch the scooter on, or 90º anticlockwise to
switch the scooter off.
• Forward, Reverse and Braking with the Wigwag paddle
• Push the wigwag paddle section marked ‘Forward’ with your right thumb and the scooter
will move forward.
• Push the wigwag paddle section marked ‘Reverse’ with your left thumb and the scooter
will move backwards. When you are reversing, the horn will beep to warn other people.
• Release the wigwag paddle and the scooter will automatically brake and come to a stop.
•
Do not push both sides of the wigwag paddle simultaneously as this may cause damage to
your scooter.
• The controls can be reversed for people who are left-handed or do not have full use of their
right arm. For more information about this please contact your dealer.
• Manual Brake
As well as an electromagnetic brake, the scooter has a manual cable brake. Squeeze the brake
lever to apply the brake then release the lever to release the brake.
•
Battery Indicator
• When the ignition is switched on the battery gauge will illuminate to indicate the
remaining battery power by the number of segments lit on the battery gauge. The
remaining power indicated by the gauge will vary by the way you drive. Driving up
inclines and repeated stopping and starting will consume power more quickly.
