PAGE 14
REAR VIEW MKIV
(Continued)
EXTERNAL SWITCHING JACKS:
POWER AMP
TRIODE SIMUL-CLASS HARMONICS
PENTODE
CLASS A
SPEAKERS
8 OHM
4 OHM
4 OHM
MID GAIN
LEAD VOICING
MODE SELECT
LEAD
EX SW
FT SW
RHY 1
RHY 2
HANDBUILT IN PETALUMA CALIFORNIA
EXTERNAL SWITCHING JACKS
RHYTHM 1
RHYTHM 2
LEAD
CLASS A/ SIMUL FX LOOP
EQ
These jacks allow remote (usually MIDI-programmed) operation of your amplifier’s functions from an external switching source, such
as the Mesa/Boogie MIDI Matrix. In each case, the switching is accomplished by connecting (“shorting”) the jack’s tip to its ring.
Your new MARK IV’s stereo capabilities can only increase your musical sound and enjoyment. Mesa/Boogie’s satellite powered
speakers - the Satellite 60 and the Simul-Satellite - which are specially designed to provide a second channel of amplification for your
Boogie combo amp and your stereo effects. The drawings below illustrate a simple hook-up procedure for going stereo. Check with
your Mesa/Boogie Pro Center or call us direct for more information if you need it, we’re always more than happy to assist you, our
new family member. Thanks !
GOING STEREO:
REV FTSW.
SATELLITE EQ
SATELLITE SEND
SATELLITE
AUTO
RHY 2
AUTO
RHY 1
FX LOOP ON
FULL TIME
FX LOOP
SWITCHING
RHY 2
LEAD
AUTO ASSIGN SWITCHES
RETURN
LEFT
(STEREO)
RIGHT
(MONO)
SIG.
PATH
FX SEND
RETURN
MARK IV (rear panel)
Stereo Effects Unit (rear panel)
LEFT & RIGHT
OUTPUTS
LEFT & RIGHT(mono)
SEND
RETURN
EFFECTS
2
3
4
5
6
7
8
9
1
0
10
EFFECTS
LEVEL
HANDBUILT IN PETALUMA CALIFORNIA
GROUND
A OFF B
2.5A
SB
FUSE
1.5A
Satellite (rear panel)
INPUTS
