Metabo BS 18 L User Manual

ENGLISHen
10
7.9 Chuck with quick change system (with
BS 18 L Quick) Fig. I
To remove: push the interlock ring forward (a),
advance and pull off the chuck forwards (b).
To fit: push the interlock ring forward and move the
chuck as far as the limit stop on the drill spindle.
7.10 Fitting the belt hook (equipment-
specific) / bit depot (equipment-specific)
Fig. J
Fit the belt hook (7) as shown.
Fit the bit depot (6) as shown.
8.1 The machine's multifunctional
monitoring system
If the machine switches off automatically, the
machine electronics have activated automatic
protection mode. A warning signal sounds
(continuous beeping). The beeping stops after a
maximum of 30 seconds or when the trigger switch
(13) is released.
In spite of this protective function, overloading
is still possible with certain applications and
can result in damage to the machine.
Causes and remedies:
1. Battery pack almost empty Fig. A, B (The
electronics protect the battery pack against
damage through total discharge).
If one LED (10) is flashing, the battery pack is
almost flat. If necessary, press the button (9) and
check the LEDs (10) to see the charge level. If
the battery pack is almost flat, it must be
recharged.
2. Long continuous overloading of the machine will
activate the temperature cut-out.
Leave the machine or battery pack to cool.
Note: if the battery pack feels very warm, the
pack will cool more quickly in an "AIR COOLED"
charger.
Note: the machine will cool more quickly if you
operate it at idling speed.
3. Metabo safety shutdown: the machine has
SHUT DOWN by itself. If the speed suddenly
drops (for example, if the machine suddenly
seizes or kickback occurs), the machine
switches off. Switch off the machine at the
trigger switch (13). Switch it on again and
continue to work as normal. Try to prevent the
machine from seizing.
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Fitting the angle drilling attachment Fig. K.
For a complete range of accessories, see
www.metabo.com or the catalogue.
Repairs to electrical tools must ONLY be
carried out by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Battery packs may not be disposed of with regular
waste. Return faulty or used battery packs to your
Metabo dealer!
Do not allow battery packs to come into contact with
water!
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-circu-
iting (e. g. by protecting them with adhesive tape).
Fig. L. We reserve the right to make technical
improvements.
U = Voltage of battery pack
n
0
= No-load speed
Tightening torque for screwing:
M
1
= Soft screwing application (wood)
M
3
= Hard screwing applications (metal)
M
4
= Adjustable torque
Max. drill diameter:
D
1 max
= in steel
D
2 max
= in softwood
D
3 max
= in masonry
s = Max. impact rate
m = Weight (with the smallest battery pack)
G = Spindle thread
D
max
= Chuck clamping range
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. The actual load may be higher
or lower depending on the operating conditions, the
condition of the power tool or the accessories.
Please allow for breaks and periods when the load
is lower for assessment purposes. Arrange
protective measures for the user, such as
organisational measures based on the adjusted
estimates.
Vibration total value (vector sum of three directions)
determined in accordance with EN 60745:
a
h, ID
= Vibration emission value
(impact drilling in concrete)
8. Troubleshooting
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Data

Metabo BS 18 L Specifications

General

Number of gears	2
Sound power level	88 dB
Chuck capacity (max)	13 mm
Chuck capacity (min)	1.5 mm
Sound pressure level	77 dB
Idle speed (1st gear)	450 RPM
Idle speed (2nd gear)	1800 RPM
Sound level uncertainty	3 dB
Drilling diameter in wood (max)	20 mm
Drilling diameter in steel (max)	10 mm
Vibration level (metal drilling)	2.8 m/s²
Maximum torque (hard applications)	50 N⋅m
Maximum torque (soft applications)	25 N⋅m
Product color	Black, Green, Red, Silver
Uncertainty K	1.5 m/s²
Power source	Battery
Battery voltage	18 V
Battery capacity	2 Ah
Battery level indicator	Yes
Chuck type	Keyless
Product design	Pistol grip drill
Number of batteries included	2 pc(s)
Maximum torque (imperial)	442.5 in⋅lbs

Weight and Dimensions

Weight	1600 g
