Midea 11MSFI-A2-1301 User Manual

10
3.2 Outdoor Unit
More than 30cm
More than 60cm
More than 70cm
More than 30cm
More than 60cm
(Service space)
Fence or
obstacles
Model
W
D
H
W1
A
B
MOC-09HFN1-QRD0W
760
285
590
823
530
290
MOC-09HFN1-QRD1W
MOC-12HFN1-QRD0W
MOC-12HFN1-QRD1W
MOC1-12HFN1-QRD0W
MOC-18HFN1-QRC8W
MOF-24HFN1-QRC8W
845
320
700
908
560
335

Midea 11MSFI-A2-1301 Specifications

General

Brand	Midea
Model	11MSFI-A2-1301
Category	Air Conditioner
Language	English

Summary

1. Precaution

1.1 Safety Precaution

General safety instructions to prevent injury, harm, or damage during operation.

1.2 Warning

Critical warnings regarding installation, electrical safety, and proper handling of the unit.

5. Wiring Diagram

5.1 Indoor Unit Wiring

5.2 Outdoor Unit Wiring

6. Installation Details

6.1 Installation Torque Specifications

Specifies torque values for tightening flare nuts and other connections during installation.

6.2 Cable Connection Guidelines

6.3 Pipe Length and Elevation Limits

Details maximum allowed pipe lengths, elevation differences, and refrigerant charging amounts.

6.4 First-Time Installation Procedures

Step-by-step guide for initial system installation, including leak testing and evacuation.

6.5 Adding Refrigerant (Post-Operation)

Procedure for adding refrigerant to the system after it has been running for an extended period.

6.6 Re-installation (Indoor Unit Repair)

6.7 Re-installation (Outdoor Unit Repair)

9. Troubleshooting

9.1 Indoor Unit Error Display Codes

9.2 Error Diagnosis and Solutions

Guides on diagnosing and resolving common errors like EEPROM, communication, sensor, and IPM faults.
