Service Manual_2020-V1.0
42
10. Compressor
10.1 Compressor on and off control specifications
1.1 When one of the following conditions is met, the compressor stops:
1) Measured temperature in refrigerator chamber ≤ Shutdown temperature of refrigerator
chamber
2) Enter defrosting cycle
3) The compressor runs continuously for more than 3 hours, will stop at least 5 minutes
1.2 When compressor shutdown time has been more than 5 min, one of the following conditions is
met, the compressor starts up:
1) Measured temperature in refrigerator chamber ≥ Start up temperature of refrigerator
2) Refrigerator is set to forced cooling mode
★When 1.1 and 1.2 are not satisfied, the compressor maintains the original state
