Midea Aqua Tempto Power Series User Manual

Aqua tempo power series tropical air-cooled scroll chiller 50Hz MCAC-ATSM-2014-09
174
1) Installation mode I (recommended installation mode)
n : the module quantity, max5
No.1 unit
No.0 address(main unit)
No.n unit (n≤5)No.(n-1) unit
No.(3n-4) address No.(3n-1) address
No.1 address No.(3n-5) address No.(3n-2) address
Pump
No.2 address No.(3n-6) address No.(3n-3) address
Drill dead hole at the
position, and move the
total effluent temperature
sensor at No.0 address to
the position
Water flow switch
2) Installation mode II
n : the module quantity, max5
Fig.4-9(less than 5 modules)
Water flow switch
Drill dead hole at the
position, and move the
total effluent temperature
sensor at No.0 address to
the position
No.1 unit
No.0 address(main unit)
No.n unit (n≤5) No.(n-1) unit
No.(3n-4) addressNo.(3n-1) address
No.1 addressNo.(3n-5) addressNo.(3n-2) address
No.2 addressNo.(3n-6) addressNo.(3n-3) address
Pump
3.5 MGBT-F250W/RN1
Multi-module combination installation involves special design of the unit, so relevant explanation is
given as follows. Installation mode of multi-module combination water system pipeline.
n : the module quantity, max8
Less than 5 modules
Less than 5 modules
