Before you begin using your new air conditioner, make sure to familiarize yourself with its remote
control. The following is a brief introduction to the remote control itself. For instructions on how to
operate your air conditioner, refer to the How to Use Basic Functions
section of this manual.
ON/OFF
SET
Turns the unit on or off.
MODE
OK
TIMER
CLEAN
LED
Turbo
Scrolls through operation modes
as follows:
AUTO
COOL
DRY
HEAT FAN
SWING
TEMP
Used to confirm the selected
functions
Starts and stops the horizontal
louver movement. Hold down
for 2 seconds to initiate vertical
louver auto swing feature.
Set timer to turn unit on or off
NOTE: HEAT mode is not supported
by the cooling only appliance.
Scrolls through operation
functions as follows:
Fresh( )
Follow Me( )
AP mode( ) Fresh...
The selected symbol will
flash on the display area,
press the OK button to
confirm.
Used to start/stop the Self
Clean function.
Turns indoor unit’s LED display
and air conditioner buzzer on and
off (model dependent), which
create a comfortable and quiet
environment.
FAN SPEED
TEMP
Enables unit to reach preset
temperature in shortest possible
time.
Selects fan speeds in the
following order:
AUTO LOW MED HIGH
NOTE: Holding this button
down for 2 seconds will
activate Silence feature.
SHORTCUT
Used to restore the current
settings or resume previous
settings.
SLEEP
Saves energy during sleeping
hours.
Model:
RG10B(D)/BGEF & RG10B(D1)/BGEFU1(Fresh feature is not available)
RG10B2(D)/BGCEF (Cooling only models, AUTO mode and HEAT mode
are not available)
RG10B10(D)/BGEF(20-28 C).
O
NOTE: For RG10B(D1)/BGEFU1 model, press together & buttons at the same time for 3
seconds will alternate the temperature display between the °C & °F scale.
Buttons and Functions
04
Decreases temperature
O O
in 1 C(1 F) increments.
Min. temperature is
O O
17 C(62 F).
Increases temperature
O O
in 1 C(1 F) increments.
Max. temperature is
O O
30 C(86 F).
To Next Page
