Midea CTBU-09HWFN1-M User Manual

9
2.3 Features
2.3.1 Duct Units
2.3.1.1 Installation Accessories: (Optional)
 Front Board, Canvas Air Passage, Filter, Panel, for easy installation
2.3.1.2 Easy Installation: Two air Inlet Styles (Bottom side or Rear side)
 Air inlet from rear is standard for all capacity; air inlet from bottom is optional.
 The size of air inlet frame from rear and bottom is same, it’s very easy to move the cover from
bottom to rear side, or from rear to the bottom, in order to matching the installation condition.
2.3.1.3 Fresh Air Intake Function
 Install one duct from the reserved fresh-air intake to outdoor.
Continually inhale the fresh air to improve the quality of the indoor air, fulfills air quality more
healthy and comfortable.
Panel
Air intake from rear (Standard)
Air intake from bottom (Optional)
