MCAC-RTSM-2009-09 Midea Heat Pump Water Heater Technical Manual
21
No.
Part Name
Quantity
BOM code
1
Water tank foam components
1
201256190027
1.1
Liner welded components
1
201256190023
1.1.1
Head on liner
1
201256100529
1.1.2
Inner barrel body
1
P0000805371
1.1.3
Terminal Block Bracket
1
201256190025
1.1.4
Temperature control components Ⅱ
2
P0000613681
1.1.5
Solar coil assembly
1
201256190019
1.1.6
Under the head liner
1
201256190024
1.1.7
Interior support frame
1
201290590109
1.1.8
Inlet components
1
P0000613631
1.1.9
Drainage fittings
1
201290590138
1.1.10
Outlet pipe components
1
P0000613665
1.2
Magnesium anode
1
202990590003
1.3
TP relief valve
1
201601601206
1.4
Three Terminal Block
1
202301400246
1.5
Thermometer
1
202301600046
1.6
Temp sensor
1
202301610028
1.7
Stator of temp. sensor
1
201290590034
1.8
seal ring of radiation pipe
1
202790590001
1.9
Electric heating pipe water
1
202403100092
1.10
Plastic foot
3
201190500293
1.11
Tank bottom
1
P0000805356
1.12
Coil rubber too
1
202790500510
1.13
Water tank handle
2
201156100038
1.14
Shell
1
P0000805335
1.15
Tank cover
1
P0000805345
1.16
Top foam liner
1
202256190001
2
Heater Cover
1
201256190015
3
Wiring nameplate
1
202056190049
