Midea MA- 12N8D0-O User Manual

4
Dimensions/Pipe and Cable Sizes/Charging
Indoor Model
Outdoor
Model
Cooling Duty
(kW)
Heating Duty
(kW)
Outdoor Dimensions
Outdoor Weight
(Kg)
Indoor Dimensions
Indoor Weight(Kg)
W(mm) D(mm) H(mm) W(mm) D(mm) H(mm)
MA-09NXD0-I MA-
09N8D0-O
3.22 3.37 700 270 550 22.7 805 205 285 7.9
MA-12NXD0-I MA-
12N8D0-O
4.10 4.22 700 270 550 22.7 805 205 285 7.9
MA-18NXD0-I MA-
18N8D0-O
6.14 6.91 800 333 554 34 958 223 302 10.3
MA-24NXD0-I MA-
24N8D0-O
8.25 8.53 845 363 702 51.5 1038 235 325 12.8
Piping Information
Model: 09 12 18 24
Liquid Line Inch 1/4 1/4 1/4 3/8
Gas Line Inch 3/8 3/8 1/2 5/8
Drain Line Φ mm 16 16 16 16
Max Length M 25 25 30 50
Max Height M 10 10 20 25
Electrical Wiring Information
Model:
09
12 18 24
Mains Outdoor
3x1.5mm² 3x2.5mm²
Interconnecting/Indoor Power
5x1.5mm² 5x2.5mm²
Power Supply Information
Model: 09 12 18 24
Outdoor Ph/A 1/16 1/16 1/16 1/20
Indoor Powered from Outdoor Unit
Refrigerant Charging Information
Model: 09 12 18 24
Pre – Charge Kg 0.5
0.5 1.0 1.6
Charged to M 5
5 5 5
Additional g/m 12
12 12 24
Refrigerant Type
R32

Midea MA- 12N8D0-O Specifications

General

Brand	Midea
Model	MA- 12N8D0-O
Category	Air Conditioner
Language	English
