The Specification of Power
J2 Floor-standing Type 137
8. The Specification of Power
Model Power supply
Input Rated Amp
(Switch/Fuse)(A)
Power Cord Size
24000Btu/h 220-240V
~
50Hz 32/25
≥2.5 mm²
(≥3.3 mm² for with PTC)
48000~60000Btu/h 380-415V
~
50Hz 32/25
≥2.5 mm²
(≥4.0 mm² for with PTC)
NOTE: The cable size and the current of the fuse or switch are determined by the maximum current indicated
on the nameplate which located on the side panel of the unit. Please refer to the nameplate before selecting the
cable, fuse and switch.
