R410A
Mini S
plit
Chiller 50Hz
MCAC-A
TSM-
20
14-01
14
9.
Piping Diagram
Remark:
No
.
Name
No
.
Name
No
.
Name
1
Compressor
6
Capillary
11
Liquid receiver
2
High pressure switch
7
Liquid receiver
12
Low pressure switch
3
4
-
wa
y valve
8
Plate heat exchanger
13
Crankcase heater
4
Condenser
9
PW
M valve
5
Filter
10
Wat
er temperature sensor
13
15
