Midea MI2-56Q4DHN1 User Manual

Accessories
Verify that the air conditioner includes the following accessories.
Installation Manual
Nut
Washer
Installation board
M6 screw
Ring clamp for water discharge pipe
Brass nut
Protection casing
Connecting wire
Foam (250x250x8)
Foam (60x100x5)
Insulation casing for copper pipe
Insulation casing for water discharge piping
Tightening band
Soft flexible hose for water discharge
Accessories to purchase locally
PVC pipe for
water discharge
Choose and purchase copper pipes that correspond to
the length and size calculated for the selected model
in the installation manual of the outdoor unit and your
actual project requirements.
Outer diameter: 37-39 mm, inner diameter: 32 mm
The inner diameter is based on the diameter of the
copper and PVC pipes. The thickness of the pipe
casing is 10 mm or more. Increase the thickness of
the casing (20 mm or thicker) when the temperature
exceeds 30°C or the humidity exceeds RH80%.
To purchase based
on actual project
requirements.
Use to connect
indoor refrigerant
piping.
Use to discharge
condensed water
from the indoor unit.
To purchase based
on actual project
requirements.
To purchase based
on actual project
requirements.
Protect piping from
condensation.
For installation
of indoor unit.
For installation
of indoor unit.
Name Appearance Dimensions Qty
Copper pipe
Insulation
casing for
piping
Expansion
hook anchor
Mounting hook
ytQecnaraeppAemaN
Code
M10
M10
4
4
Note
1
2
3
4
5
1
1
8
8
4
2
1
1
1
1
11
1
1
3
1
1
3
2
4
5
6
7
8
9
10
11
12
13
14
15
Code
3
