Service manual
- 7 -
4. Specification
MSG-09CR-QC3 MSG-09HR-QC3 MSG-12CR-QC2
Ph-V-Hz
1, 220-240V~,50Hz 1, 220-240V~,50Hz 1, 220-240V~,50Hz
Capacity W 2600 2600 3400
Input W 770 770 1050
Rated current A 3.6 3.6 4.6
EER W/W 3.37 3.37 3.24
Capacity W ---- 3000 ----
Input W ---- 910 ----
Rated current A ---- 4 ----
COP W/W ---- 3.30 ----
A6 6 7
A192022
Model 2P15S225ANH 2P16S225ANC PH200X2C-4FT3
Type Rotary Rotary Rotary
Brand
Matsushita
Matsushita Toshiba
Capacity W 2450/2460 2635/2670
3440/3470
Input W 795/835 840/875 1080/1090
Rated current(RLA) A 3.75/3.65 3.9/3.7 5/4.65
Locked rotor Amp(LRA) A 17.2/18.8 18/19.6 21.6
Thermal protector B160-150-241H B165-150-241H UP3RE0591-T56
Capacitor uF 25 30 35
Refrigerant oil ml 350 350 480
Model RPG13H RPG13H RPG20D
Brand WELLING WELLING WELLING
Input W 36.5 36.5 49.2
Capacitor uF 1.2μF/450V 1.2μF/450V 1.5uF/450V
Speed(hi/mi/lo) r/min 1250/1100/1000 1250/1100/1000 1120/900/800
m3/h 500/420/390 500/420/390 600/520/480
dB(A) 37/34/31 37/34/31 39/34/30
Model YDK24-6F YDK24-6F
YDK24-6F
Brand WELLING WELLING Welling
Input W 56 56 56
Capacitor uF 2.5 2.5 2.5
Speed r/min 800 800 800
m
3
h
1800 1800 1900
dB(A)535354
g 1050 1100 1080
MPa 2.6 2.6 2.6
Liquid side/ Gas side mm Ф6.35/Ф9.53 Ф6.35/Ф9.53 Ф6.35/Ф12.7
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30 17-30 17-30
℃
18-45 -7 - 45 18-45
m
2
14-21 14-21 18-26
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R22
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
