Service manual 7
3. Specification
Indoor model name MSMA1A-07HRN1 MSMA1A-09HRN1 MSMA1B-12HRN1
Outdoor model name MOAB02-07HN1 MOAB02-09HN1 MOBA01-12HN1
Power supply
Ph-V-H
z
220-240V- 50Hz, 1Ph 220-240V- 50Hz, 1Ph 220-240V- 50Hz, 1Ph
Cooling
Capacity
Btu/h 7000 9000 12000
kW 2,05 2,64 3,52
Input W 639 822 1096
Rated current A 2.8 3.6 4.8
EER W/W 3,21 3,21 3,21
Heating
Capacity
Btu/h 8000 9500 13000
kW 2,34 2,78 3,81
Input W 649 771 1055
Rated current A 2.8 3.4 4.8
COP W/W 3,61 3,61 3,61
Max. input consumption W 1050 1200 1800
Max. current A 5.5 6.0 9.0
Starting current A 16.1 21.7 25
Compressor
Model ASN82V1UDZ 44M213AH&FJKC ASM140V1VFT
Type ROTARY ROTARY ROTARY
Brand GMCC Rechi GMCC
Capacity Btu/h 6995/7029 8428/8530 13853/13853
Input W 702/735 830/860 955/995
Rated current(RLA) A 3.21/3.15 3.85/3.73 4.35/4.2
Locked rotor Amp(LRA) A 16.1 21.7 25
Thermal protector ----- B160-135-241E /
Thermal protector
position
EXTERNAL EXTERNAL INTERNAL
Capacitor uF 25 40 35
Refrigerant oil/oil
charge
ml ESTEL OIL VG74/300 ESTER OIL VG74 350cc ESTER OIL VG74/350
Indoor fan
motor
Model YKFG-13-4-38L YKFG-13-4-38L YKFG-13-4-38L
Input W 40 40 40
Capacitor uF 1.2 1.2 1.2
Speed(Hi/Mi/Lo) r/min 1050/950/800 1100/950/800 1150/950/800
Indoor coil
a.Number of rows 2 2 2
b.Tube pitch(a)x row
pitch(b)
mm
19.5x11.6 19.5x11.6 19.5x11.6
c.Fin spacing mm 1.2 1.2 1.2
d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and
type
mm
Φ5,innergroove tube Φ5,innergroove tube Φ5,innergroove tube
