Outdoor Unit Disassembly 47
3.5 Sound blanket
Note: Remove the panel plate (refer to 3.1 Panel plate) before disassembling sound blanket.
Procedure Illustration
1) Remove the sound blanket (side and
top) (see CJ_ODU_BLANKET_001).
CJ_ODU_BLANKET_001
Note: This section is for reference only. Actual unit appearance may vary.
Sound Blanket(side)
Sound Blanket(top)
