VC Pro VRF 50/60Hz
38
64/66/68HP
Figure 2-2.10: 64/66/68HP dimensions (unit: mm)
70/72/74/76HP
Figure 2-2.11: 70/72/74/76HP dimensions (unit: mm)
1615
765
1585
1250
765
200-500
200-500
Outdoor unit 1 Outdoor unit 2
Outdoor unit 3
960
765
1615
765
1585
765
1585
200-500
200-500
960
765
Outdoor unit 1
Outdoor unit 2
Outdoor unit 3
