Midea R410A Direct Heating Type HPWH 50Hz Technical Manual MCAC-HTSM-201906
33
8 Electrical characteristics
Table 2-8.1: Electrical Characteristics
Model
RSJ-120/ZN1-540V1
RSJ-200/SZN1-540V1
RSJ-420/SZN1-H
RSJ-800/SZN1-H
Outdoor
unit
50
50
50
50
50
Voltage
220~240V, 1Ph
380~415V, 3Ph
380~415V, 3Ph
380~415V, 3Ph
Min.
198V
342V
342V
342V
Max.
264V
456V
456V
456V
Power
supply (A)
MCA
9.7
10.5
21
26
TOCA
20
18
30
60
MFA
32
18
30
60
Compressor
(A)
MSC
98
74
118
142
RLA
17.7
11.8
16.6
20.7
OFM
Rated motor
output(kW)
0.2
0.13
0.8
0.8
FLA
1.2
1.1
3.7
3.7
Abbreviations:
MCA: Min. Current Amps. (A) MFA: Max. Fuse Amps. (A)
TOCA: Total Over-current Amps. (A) MSC: Max. Starting Amps. (A)
RLA: Rated Locked Amps. (A) OFM: Outdoor Fan Motor
FLA: Full Load Amps. (A)
