PARTS NAMES
NOTE
All the picture in this manual are for explanation purpose only. They may be slightly different from the heat pump water heater you
purchased (depending on model). Please refer to the real product instead of the picture of this manual.
When ordering repair parts please always give the following information:
1) Model, serial and product number.
2) Part name on location.
Fan Assy
PTR Valve
Top Cover
Evaporator Filter
Magnesian Stick
Rear Cover
Front Cover
Water Outlet
Water Inlet
Drain port
Electric Heater
Front Decorative Board
Temperature Sensor T5
Electronic Control Box
Power Connect Box and cover
Compressor
Display
Magnesian Stick Cover
ATCO
TCO
Electric Heater Cover
