05
PRODUCT INSTALLATION
Install Instruction
For refrigerating appliances with climate class
• Depending on the climate class, This refrigerating appliance is intended to be
used at ambient temperatures range as specied following table.
• The climate class can be found on the rating plate. The product may not
operate properly at temperatures outside of the specic range.
• You can nd the climate class on the product label.
Effective temperature range
• The product is designed to operate normally in the temperature range
specied by its class rating.
Class Symbol
Ambient temperature range °C
IEC 62552 (ISO 15502) ISO 8561
Extended temperate SN + 10 to + 32 + 10 to + 32
Temperate N + 16 to + 32 + 16 to + 32
Subtropical ST + 16 to + 38 + 18 to + 38
Tropical T + 16 to + 43 + 18 to + 43
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation
of freezing capability and increased electricity costs. Allow over 100 mm of
clearance from each adjacent wall when installing the appliance.
>100mm
>100mm
>100mm
>100mm
>100mm
>100mm
Top View
Required space
for air circulation
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor
To Next Page
